#HiDefNES kits have been delivered to me, well the first 150 anyway, they aren’t FW updated tho sorry, blame kevtris!
So now I pre assemble interposers!
Kevtris’s post on nesdev:
Well here it is, after 14 months!
* Audio DC level restoration to fix some monitors that’d be silent or have other weird audio volume issues.
* FDS channel redone to be hopefully more accurate.
* DPCM fixed to allow retriggering.
* Address bus filtering fixed so that graphical/palette glitches should be a thing of the past.
* PAL pixel capturing fixed.
* 4 new palettes added.
* Removed interpolation and associated menu. I needed the logic gates in the FPGA to fix the other things.
I tested 5 sets of PAL chips- 1 set always worked, but the other 4 had minor to very severe “speckling”. These are all working perfectly now.
I tested 3 sets of “laser H rev” parts as found in the newest AV famicoms (I think) and they are all working perfect now as well.
This should fix all the problems people had I hope.
This update is a beta because I am not 100% sure I didn’t break something else relating to DPCM, so if I did please let me know.
The four new palettes are:
Firebrand X NTSC
Firebrand X PVM D93
The original 4 palettes are still in there of course.
Hope that’s enough because this thing is fulllllllll up. There is absolutely no room left anywhere. I have scavenged it all. btw,
the xray mode is “free” so it doesn’t use any logic elements. It’s the internal decisions being made about the HQX stuff. It’s basically detecting edges.
I slightly changed the way DPCM works, so it should be correct now with regards to retriggering it. It will only retrigger now if the sample is done playing, instead of retriggering no matter what.
Also, I bumped the volume up by a factor of 4 for sunsoft 5B since it was kinda quiet.
I noticed something really weird though with DPCM. I have a laser H rev CPU here and the DPCM is… corrupt on it sometimes. I tested with the 2.25 rev of firmware and it does it there, too so it isn’t something new I introduced.
Using a legit SMB3 cart, it works fine- DPCM drums play OK, game works fine. I tested both composite and Hi def outputs.
Using a powerpak, though (with powermappers) DPCM is kind of broken. Samples end earlier than they should, like the length isn’t being programmed right. The analog audio coming out of the CPU is broken in the same way, and watching the CPU bus the sample fetching just stops! I am at a loss as to what’s going on here. Needless to say, it only happens with one specific CPU chip out of the dozen or so test samples, so I am not sure what’s going on. I am suspecting the chip might be flaky somehow.
Kev spent some time working on some bugs, click the link to see the forum post on nesdev with the details:
There are no more kits available for pre order until next round, and no I have no idea when that will be!
Batch will be ordered on 4-21-17, they should get to me within a couple months, watch here or twitter for more updates.
Stock reduced to 35 in order meet a deadline set by Marshall to put in the big order.
What this means is the order is being put in friday whether pre orders are sold out or not, I have the funds to cover the orders so far plus the remaining left up now for pre order, but I think they will all be sold quickly anyway.
So good news for ppl who pre ordered early!
I keep getting emails asking for updates, but I don’t really post them until there’s something solid to post, but I can at least say that kits are at Kevtris’s place, but when they will get to me is not known yet.
PCBs have cleared customs and been delivered to Marshall. FFCs are still in production. 1-2 more weeks until shipped to me.
The next batch of kits has already been ordered!
500 more were ordered yesterday. Last time it was about a month from order to receipt.
We’re doing yellow solder mask again as we had a lot of extra interposers last batch.
Again, there really hasn’t been much difference in the hardware for this project from day one so the solder mask colors don’t mean much.
